Rigid Aluminum Conduit Elbows/Bends
Rigid aluminum conduit elbow is manufactured from prime rigid aluminum conduit shell with high-strength in accordance with the latest specifications and standard of ANSI C80.5(UL6A).
Rigid aluminum conduit elbow is manufactured from prime rigid aluminum conduit shell with high-strength in accordance with the latest specifications and standard of ANSI C80.5(UL6A).
Elbows are produced in normal trade sizes from 1/2” to 6”, the degrees including 90 deg, 60 deg ,45 deg, 30 deg,22.5deg,15deg or according to customer’s request .
Elbows are threaded on both ends,a thread protector with industry color-coded by sizes from 3” to 6” applied.
The elbows are used to connect the rigid aluminum conduit to change the way of the conduit.
Dimension and Packing Chart
| ALUMINUM RIGID ELBOW | SIZE | Mini.UL Radius “A” | Offset “B” | Weight per 100PCS | PCS/ Carton | Weight/ Carton | ||||
| 90DEG ELBOW | mm | in. | mm | in. | KG | LBS | KG | LBS | ||
 |
1/2″ | 102 | 4.016 | 145 | 5.689 | 10.0 | 22 | 50 | 5.00 | 11 |
| 3/4″ | 114 | 4.488 | 169 | 6.654 | 15.7 | 35 | 50 | 7.85 | 17 | |
| 1″ | 146 | 5.748 | 206 | 8.110 | 27.7 | 61 | 20 | 5.54 | 12 | |
| 1-1/4″ | 184 | 7.244 | 254 | 10.000 | 44.6 | 98 | 20 | 8.92 | 20 | |
| 1-1/2″ | 210 | 8.268 | 290 | 11.417 | 63.0 | 139 | 10 | 6.30 | 14 | |
| 2″ | 241 | 9.488 | 331 | 13.031 | 95.8 | 211 | 10 | 9.58 | 21 | |
| 2-1/2″ | 267 | 10.512 | 387 | 15.236 | 177.4 | 391 | 50 | 88.70 | 196 | |
| 3″ | 330 | 12.992 | 465 | 18.307 | 278.7 | 614 | 35 | 97.55 | 215 | |
| 3-1/2″ | 381 | 15.000 | 536 | 21.102 | 385.4 | 850 | 35 | 134.89 | 297 | |
| 4″ | 406 | 15.984 | 571 | 22.480 | 484.7 | 1069 | 25 | 121.18 | 267 | |
| 5″ | 610 | 24.016 | 893 | 35.157 | 1030.8 | 2272 | BULK | |||
| 6″ | 762 | 30.000 | 1099 | 43.268 | 1664.2 | 3669 | BULK | |||
| ALUMINUM RIGID ELBOW | SIZE | Mini.UL Radius “A” | Offset “B” | Weight per 100PCS | PCS/ Carton | Weight/ Carton | ||||
| 45DEG ELBOW | mm | in. | mm | in. | KG | LBS | KG | LBS | ||
 |
1/2″ | 102 | 4.016 | 64 | 2.520 | 7.2 | 16 | 50 | 3.60 | 8 |
| 3/4″ | 114 | 4.488 | 72 | 2.835 | 10.7 | 24 | 50 | 5.35 | 12 | |
| 1″ | 146 | 5.748 | 84 | 3.307 | 18.2 | 40 | 35 | 6.37 | 14 | |
| 1-1/4″ | 184 | 7.244 | 104 | 4.094 | 29.5 | 65 | 30 | 8.85 | 20 | |
| 1-1/2″ | 210 | 8.268 | 120 | 4.724 | 42.4 | 93 | 15 | 6.36 | 14 | |
| 2″ | 241 | 9.488 | 142 | 5.591 | 66.7 | 147 | 15 | 10.01 | 22 | |
| 2-1/2″ | 267 | 10.512 | 160 | 6.299 | 118.3 | 261 | 50 | 59.15 | 130 | |
| 3″ | 330 | 12.992 | 203 | 7.992 | 197.5 | 435 | 40 | 79.00 | 174 | |
| 3-1/2″ | 381 | 15.000 | 239 | 9.409 | 279.5 | 616 | 35 | 97.83 | 216 | |
| 4″ | 406 | 15.984 | 261 | 10.276 | 359.8 | 793 | 35 | 125.93 | 278 | |
| 5″ | 610 | 24.016 | 377 | 14.843 | 703.9 | 1552 | BULK | |||
| 6″ | 762 | 30.000 | 452 | 17.795 | 1107.2 | 2441 | BULK | |||
REMARK: Elbows with special radius or special degree available upon request.
